Passive Dwdm Fiber Optic Mux Demux Module 200ghz Multiplexer And Demultiplexer

Passive Dwdm Fiber Optic Mux Demux Module 200ghz Multiplexer And Demultiplexer

Description

DWDM MUX DEMUX Modules with 50GHz/100GHz/200GHz channel spacing can be used to combine or separate wavelength channels at standard ITU grid. We supply the common configuration including 2, 4, 8, 16, 24, 32, 40, 44, and 48 channels.

These DWDM modules passively multiplex the optical signal outputs from 4 or more electronic devices, and send them over a single optical fiber and then de-multiplex the signals into separate, distinct signals for input into electronic devices at the other end of the fiber optic link.

Our standard package types of DWDM MUX DEMUX are Field Module ABS Plastic Box, 19" Rack Mount Chassis and LGX Metal Cassette Box. We also supply custom package to meet customers' requirements. All the DWDM MUX DEMUX modules provide excellent optical performance and high reliability to ease of fiber handling and power saving solution Duplex DWDM MUX & DEMUX

Technical Specs for 200GHz DWDM

Parameter	Unit	Value
Channels Number	-	2	4	8	16	20
Channel Central Wavelength	nm	ITU-T Grid
Passband at 0.5dB	nm	≥0.6
Pass band	nm	λITU±0.25
Pass band Flatness	dB	≤0.5
Insertion Loss (Typ.)	dB	1.2	2.0	4.2	9.0	16.8
Insertion Loss (Max.)	dB	1.4	2.6	5.0	9.8	19.4
Adjacent Channel Isolation	dB	≥25
Non-adjacent Channel Isolation	dB	≥40
Return Loss	dB	≥45
Polarization Mode Dispersion	ps	≤0.10	≤0.10	≤0.10	≤0.15	≤0.15
Polarization Dependent Loss	dB	≤0.10	≤0.15	≤0.20	≤0.25	≤0.25
Directivity	dB	≥50
Operation Temperature	°C	-5~+70
Storage Temperature	°C	-40~+85
Package Dimension	mm	ABS box G: 100X80X10, H: 125X96X16 I: 141X115X18, O: customized

Multiplexer (MUX) and demultiplexer (DEMUX) are combined together into a single piece of equipment for bi-directional data transmission over two fibers.

Fs Three-types-transmission-way-for-Fiberstore-DWDM-MUX-DEMUX-Duplex-BIDI.jpg
