Sfp Optical Transceiver 16gbase-Lr 1310nm 10km Sm Fiber TUV / UL Certification

Sfp Optical Transceiver 16gbase-Lr 1310nm 10km Sm Fiber TUV / UL Certification

Overview

16G SFP+ LR transceivers, according to 16 Gigabit Small Form Factor Pluggable “SFP+” Multi-Sourcing Agreement (MSA) SFF-8431 Rev. 3.0 and SFF-8472 Rev. 11.0, are designed for use in Fibre Channel links up to 14.025Gb/s data rate and up to 10km link length. They are compatible with FC-PI-5 Rev. 6.10 and SFF-8432.16G SFP+ LR offer commercial operating temperature options.

Features

Up to 14.025Gb/s bi-directional data links
Electrical interface specifications per SFF-8431
Management interface specifications per
SFF-8432 and SFF-8472
SFP+ MSA package with duplex LC connector
Build-in Dual CDR at 14.025Gb/s and bypass at 4.25Gb/s and 8.5Gb/s
Uncooled 1310nm DFB Laser
Up to 10 km on 9/125um SMF
Single +3.3V power supply
Class 1 laser safety certified
1.8W maximum power consumption with established link
Operating temperature Options-(Commercial) 0oC to +70oC
RoHS Compliant

Parameter

Package (Form Factor)	SFP+
Data Rate (typical)	14.025 Gb/s
Centre Wavelength	1310nm
Distance	10km
Diagnostics	Digital Monitor
Transmitter	DFB Laser
Receiver	PIN photo detector
TX Output Power (dBm)	-5~+2
RX Sensitivity (dBm)	-12
Low/High Case Temperature	0°C~70°C
Voltage Supply (typical)	3.3v
Connector	Duplex LC/UPC

Application

Tri Rate 4.25 / 8.5 / 14.025 Gb/s Fibre Channel Rate

Advantage
1. Excellent quality and 3 years warranty
2. Competitive pricing
3. Full compatible (HP/Extreme/Juniper/H3C…)
4. OEM/ODM Customized label
5. Keep stock,Fast delivery
