100G Cfp Optical Transceiver For Cfp-100gb-Er4 Compatible

Ask Lasest Price
Brand Name :	Sourcelight or OEM
Model Number :	Cfp-100gb-Er4
Certification :	CE/FCC/RoHS/TUV/UL
Price :	Get Latest Price
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	100PCS Per Week
Delivery Time :	Shipped in 1 days after PO confirmed

Add to Cart

Product Details
Company Profile

100G Cfp Optical Transceiver For Cfp-100gb-Er4 Compatible

100G Cfp Optical Transceiver For Cfp-100gb-Er4 Compatible

Overview

100G CFP ER4 CFP-100G-ER4 compliant with the CFP MSA1, IEEE 802.3ba 100GBASE-LR42 and OTU4 4I1-9D1F requirements specified in ITU-T Recommendations G.959.1/G.709 and Supplement 39 (G.sup39). Digital diagnostics functions are available via the MDIO interface. The transceiver is RoHS-6 compliant and lead-free.

Features

Supports 103.1Gb/s and 112Gb/s aggregate bit rates
Power dissipation < 18W
RoHS-6 compliant (lead-free)
case temperature range of 0°C to 70°C
Single 3.3V power supply
Maximum link length of 40km on Single Mode Fiber
4x28Gb/s DFB-based LAN-WDM transmitter
10x10G MLD electrical interface

Parameter

Package (Form Factor)	CFP-100Gb-ER4
Data Rate (typical)	100GBASE
Centre Wavelength	1310nm(Center)
Distance	40KM SMF
DDM	HAVE
Transmitter	4x28Gb/s DFB LASER
Receiver	PIN
TX Output Power	-4.3~+4.5(dBm)
RX Sensitivity	-8.6(dBm)
Low/High Case Temperature	0°C~70°C
Voltage Supply (typical)	3.3v
Connector	Duplex LC/UPC

Application

OTN OTU4 4I1-9D1F
100GBASE-LR4 100G Ethernet

100G CFP LR4 Product

PN	Description
100G-CFP-ER4	100G ER4 CFP Transceiver 40km over SMF

Competitive advantage
1. Excellent quality and 3 years warranty
2. Competitive pricing
3. Full compatible (HP/Extreme/Juniper/H3C…)
4. OEM/ODM Customized label
5. Keep stock,Fast delivery
