DFB Laser Transmitter Optical Transceiver Tx1550 Rx1490nm For 10gbase Ethernet

Ask Lasest Price
Brand Name :	Sourcelight or OEM
Model Number :	10g BIDI SFP+ 80km
Certification :	CE/FCC/RoHS/TUV/UL
Price :	Get Latest Price
Payment Terms :	L/C, D/A, D/P, T/T, Western Union
Supply Ability :	200PCS Per Week
Delivery Time :	Shipped in 1 days after PO confirmed

Add to Cart

Product Details
Company Profile

DFB Laser Transmitter Optical Transceiver Tx1550 Rx1490nm For 10gbase Ethernet

DFB Laser Transmitter Optical Transceiver Tx1550 Rx1490nm For 10gbase Ethernet

Overview

10G SFP+ BIDI 80KM transceiver is designed to be compliant with SFF-8472 and SFP+ MSA.

The module data link up to 80km in 9/125um single mode fiber.

The optical output can be disabled by a LVTTL logic high-level input of Tx Disable.

Tx Fault is provided to indicate that degradation of the laser. Loss of signal (LOS) output is provided to indicate the loss of an input optical signal of receiver or the link status with partner.

Features

SFP MSA package with single LC connector
Typical bidi 1490/1550nm and 1550nm/1490nm for commission
APD receiver for high sensitivity
Very low EMI and excellent ESD protection
Digital Diagnostic Monitor Interface
Hot pluggable
Support 9.95Gb/s to 11.1Gb/s serial optical interface
Up to 80km distance
Below <1.5W power consumption

Parameter

Package (Form Factor)	SFP+ BIDI 80KM 10g
Data Rate (typical)	10.3 Gbps
Centre Wavelength	Tx1490nm/Rx1550nm
Distance	80km on smf
Diagnostics	Digital Monitor
Transmitter	DFB Laser
Receiver	APD photo detector
TX Output Power (dBm)	+1~+6
RX Sensitivity (dBm)	-24
Low/High Case Temperature	0°C~70°C
Voltage Supply (typical)	3.3v
Connector	Simplex LC/UPC

Application

10GBASE-BX 10.3125Gb/s Ethernet
10GBASE-BX 9.953Gb/s Ethernet
SONET OC-192 &SDH STM I-64.1

Competitive advantage
1. Excellent quality and 3 years warranty
2. Competitive pricing
3. Full compatible (HP/Extreme/Juniper/H3C…)
4. OEM/ODM Customized label
5. Keep stock,Fast delivery

Sourcelight BIDI SFP+

BIDI (WDM) SFP+
P/N	Data Rate	Distance	Wavelength	FP	PD	Media
BIDI SFP+ 60KM	10G/ps	60KM	TX1330	DFB	APD	SM
BIDI SFP+ 60KM	10G/ps	60KM	TX1270	DFB	APD	SM
BIDI SFP+ 40KM	10G/ps	40KM	TX1330	DFB	PIN	SM
BIDI SFP+ 40KM	10G/ps	40KM	TX1270	DFB	PIN	SM
